Ozone Aging Chamber - ZSY-37 Model

Explore the ZSY-37 Ozone Aging Box, a specialized testing device designed for evaluating the performance of rubber and other materials under controlled ozone exposure conditions.

This chamber is ideal for laboratories and research institutions conducting aging tests on products exposed to ozone in static tensile deformation environments. It simulates real-world conditions without direct sunlight, ensuring accurate and reliable results.

The equipment features advanced temperature control systems with high precision and stability, making it suitable for a wide range of applications. Whether you're testing rubber compounds or other materials, this chamber provides consistent and repeatable test conditions.

Overview:

The Ozone Aging Test Chamber is an essential climate simulation tool used to assess the durability of vulcanized rubber and similar materials. It exposes samples to a controlled ozone atmosphere and temperature environment, allowing researchers to evaluate long-term performance and resistance to degradation.

Designed for use in scientific research centers and industrial laboratories, the ZSY-37 model ensures precise control over key environmental factors, including ozone concentration, temperature, and humidity.

Main Technical Specifications:

• Ozone Concentration Range: 0ppm ~ 5ppm
• Temperature Range: Room Temperature ~ 50°C
• Temperature Uniformity: ±2°C
• Temperature Fluctuation: ±0.5°C
• Test Piece Speed: 20 ~ 25 rev/min
• Cycle Motor: 25W
• Turntable Motor: 370W (Optional)
• Power Supply Voltage: 220V
• Frequency: 50Hz

Structural Features:

• High-quality cold-rolled steel casing with electrostatic spray finish, and stainless steel inner chamber for durability and corrosion resistance.
• High-efficiency corona discharge ozone generator for accurate ozone generation.
• Digital display of ozone concentration with imported sensors for precise control.
• Advanced temperature controller for stable and accurate regulation.
• Stainless steel turntable with adjustable fixtures to meet standard testing requirements.
• LED digital display for ozone concentration, with built-in over-temperature protection, automatic power-off, and short-circuit protection features.

Operating Conditions:

• Temperature: 15°C ~ 35°C
• Relative Humidity: ≤85% RH
• Atmospheric Pressure: 86 ~ 106 kPa
• No strong vibrations or direct sunlight exposure
• No strong electromagnetic fields or corrosive substances nearby
• Ensure at least 60 cm of clearance around the unit for safe operation

Safety Precautions:

• Install external protection mechanisms and follow the nameplate voltage requirements.
• Do not use for flammable, explosive, toxic, or corrosive materials.
• Install the equipment horizontally and avoid unauthorized disassembly.
• Ensure proper grounding and avoid opening the door unless necessary.
• Monitor the inside of the chamber when the door is locked from the outside.
• Regularly check protective functions and address any alarms promptly.
• Always operate the equipment safely and follow all guidelines.

Operation Method:

1. Turn on the power switch, set the desired ozone concentration, temperature, and test duration using the control panel.
2. Fix the test sample on the turntable and adjust the tension as required.
3. Close the door and start the automated process by activating the panel buttons.

Note:

• Refer to the instrument manual for detailed operation instructions.
• Ozone concentration may have a slight delay upon startup, which is normal.
• The temperature controller operates within 0°C ~ 99.9°C; temperatures below 0°C will not be displayed.

Daily Maintenance:

• Turn off the power circuit breaker after each test session.
• Replace or repair faulty electrical components with compatible parts.
• Only trained personnel should handle maintenance and operation.

Important Notes:

All items marked with "!" are critical actions or important considerations. The actual performance of the equipment may vary slightly depending on the order. Due to continuous product improvements, technical parameters and structural details may change without prior notice. Please refer to the official instructions provided by the company's commissioning team for full guidance.

If you find any issues or areas for improvement, we welcome your feedback. Your input helps us enhance our products and continue to support your needs.
